ZIVELAB has provided electrochemical instruments design and developemt in hardware and software.,

      ZIVELAB 's multichannel potentiostat/galvanostat/ZRA  are following 4 models.
       These models use SmartManger software for control and data aquisition.

     ZIVE MP1 Multichannel potentiostat/galvanostat/ZRA

    The ZIVE MP1 is an economical multichannel electrochemical workstation having capability of electrochemical impedance spectroscopy (EIS). This system can be configured from 4 to 16 channels which can be controlled independently. The Zive MP1 is able to provide current output of up to ±1A. Each channel has ZRA circuit for galvanic corrosion.

      The ZIVE MP2A is a high quality multichannel electrochemical workstation having capability of electrochemical impedance spectroscopy (EIS). This system can be configured from 4 to 32 channels which can be controlled independently. The Zive MP2 is able to provide current output of up to ±2A. Each channel has ZRA circuit for galvanic corrosion.

    ZIVE MP2C Multichannel potentiostat/galvanostat/ZRA
                                  for multi working electrodes with one reference / one counter electrode

      The ZIVE MP2C is a  spin off model from ZIVE MP2 for multiple working electrodes with one reference/ one counter electrode configuration. Specification and function is same as ZIVE MP2. This system can be configured from 4 to 32 channels which can be controlled independently. The Zive MP2 is able to provide current output of up to ±2A. Each channel has ZRA circuit for galvanic corrosion.

     ZIVE MP5 Multichannel potentiostat/galvanostat/ZRA

      The ZIVE MP5 is a high quality multichannel electrochemical workstation having capability of electrochemical impedance spectroscopy  (EIS).  This system can be configured from 4 to 32 channels which can be controlled independently. The Zive MP5 is able to provide  current output of up to ±5A.   This feature makes Zive MP5 perfect for some applications  higher current levels required.

     ZIVE MP5H Multichannel potentiostat/galvanostat/ZRA

    The ZIVE MP5H is a high control voltage multichannel electrochemical workstation having capability of electrochemical impedance spectroscopy  (EIS).  This system can be configured from 4 to 32 channels which can be controlled independently. The Zive MP5H is able to provide  current output of up to ±1A with max ±40Volt control voltage.   .

     ZIVE MP5HC  Multichannel potentiostat/galvanostat/ZRA

    The ZIVE MP5HC is a high compliance voltage multichannel electrochemical workstation having capability of electrochemical impedance spectroscopy  (EIS).  This system can be configured from 4 to 32 channels which can be controlled independently. The Zive MP5HC is able to provide  current output of up to ±1A with Max ±44Volt compliance voltage.





     ZIVE SM SmartManager Software

      The ZIVE SM SmartManager program is for control and data acquisition of Zive potentiostat/ galvanostat. This is for single- and multi-channel system.
